Distek Evolution 6300 - Printouts; Serial Port Control

Chapter 3: Operation
Operation Manual: Evolution Series
3
-
40
Printouts
The Evolution Series contains several types of printouts. The unit is capable of
printing real-time test reports, saved reports, InstaPrint, method settings, user
settings and calibration data. See Appendix E for sample printouts.
To configure printing simply connect a printer cable from the printer port located
on the side of the system to the printer. If multiple units will be sharing one
printer see Printer Sharing Configuration on page 3-9.
InstaPrint can be selected any time the heaters and RPM are enabled. The units
will printout applicable information depending on whether an AUTO test or
MANUAL test is running. Printouts are created by pressing the PRINT menu bar
item located on several screens throughout the user interface.
Serial Port Control
AA represents the unit address.
Command Response Function
[AA CONT:VESL:TEMP NNN] [NNN]
Set temperature (NN.N°C) for all enable
vessels
[AA CONT:VESL:TEMP X,NNN] [X,NNN] Set temperature (NN.N°C) for vessel X
[AA CONT:VESL:ELEM 'TYPE'] [PADDLE] or [BASKET]
Set stir type for all vessels, where 'TYPE' is
PADDLE or BASKET.
[AA CONT:VESL:ELEM
X,'TYPE']
[X,PADDLE] or [X,BASKET]
Set stir type for vessel X, where 'TYPE' is
PADDLE or BASKET.
[AA CONT:VESL:VOL NNNN] [NNNN] Set volume (NNNN mls) for all vessels
[AA CONT:VESL:VOL X,NNNN] [X,NNNN] Set volume (NNNN mls) for vessel X
[AA CONT:VESL:STAT X, ON] [X,ON] Enable vessel X.
[AA CONT:VESL:STAT X, OFF] [X,OFF] Disable vessel X.
[AA CONT:VESL:ENBL
1234567]
[!] Enable vessel 1, 2 3, 4, 5, 6 & 7.
[AA CONT:VESL:ELEM?] [PADDLE] or[BASKET] Report the stirring type for all vessels.
[AA CONT:VESL:ELEM? X] [PADDLE] or[BASKET] Report the stirring type for vessel X.
[AA CONT:VESL:TEMP?] [NNN]
Report the set point temperature (NN.NN°C)
for all vessels.
[AA CONT:VESL:TEMP? X] [NNN]
Report the set point temperature (NN.NN°C)
for vessel X.
[AA CONT:MOTO:SET NNNN] [NNNN] Set the RPM (NNNN).
[AA CONT:MOTO:STAT ON] [ON] Turn the motor on.
[AA CONT:MOTO:STAT OFF] [OFF] Turn the motor off.
