Conduct a Bore - 126 JT40/JT40 All Terrain Operator’s Manual
Assemble Drill String
Attach Downhole Tool
See “Hydratong Wrenches” on page 169.
Machine Torque
1. Remove blocks from pipe guides.
2. Pull tool into lower wrench.
3. Close wrench.
4. Use machine torque to tighten joint fully.
Quick Wrenches
1. Lube joints with TJC (tool joint compound).
2. Attach quick wrenches to the joint in the join position and tighten joint.
AT Dirt Mode (AT Pipe)
1. bit
2. beacon housing
3. adapter
4. collar
5. transition sub
6. JT40 AT drill pipe
JT Mode
1. bit
2. beacon housing
3. adapter
4. collar
5. transition sub
6. JT40 drill pipe (Power Pipe
®
HD or HIWS1 Pipe)
EZ_Connects2016.eps
