Conduct a Bore - 132 JT40/JT40 All Terrain Operator’s Manual
Add Pipe
5. Connect pipe to SaverLok
®
body.
6. Connect new pipe.
Manual Pipeloader Controls Automated Pipeloader Control
IMPORTANT: Always rotate clockwise unless
breaking pipe joint. Rotating counterclockwise
will separate joints.
• Move carriage forward until SaverLok
meets pipe.
• Rotate spindle clockwise until SaverLok
threads onto pipe.
• Relax grippers.
IMPORTANT: Always rotate clockwise unless
breaking pipe joint. Rotating counterclockwise
will separate joints.
• Move carriage forward until SaverLok
meets pipe.
• Rotate spindle clockwise until SaverLok
threads onto pipe.
• Press RESUME. Grippers will relax.
Manual Pipeloader Controls Automated Pipeloader Control
• Slowly move carriage forward to allow inner
rod to match up and rotate spindle
clockwise until pipe threads together.
• To fully tighten joint, slowly rotate pipe until
spindle stops turning.
• Open wrench.
• Open grippers fully.
• Retract shuttles.
• Lower pipe lifters.
• Slowly move carriage forward to allow inner
rod to match up and rotate spindle
clockwise until pipe threads together.
• Press RESUME. Display changes to
“Retracting Shuttles.” Grippers open,
shuttles retract, pipe lifters lower and
display reads “Lowering Pipe.” Display
changes to “Open Front Wrench.”
• To fully tighten joint, slowly rotate pipe until
spindle stops turning.
• Open wrench. If wrench will not open, look
at upper display for operation messages.
To Next Page
