JT40/JT40 All Terrain Operator’s Manual Service - 235
As Needed
Replace SaverLok
®
Body
Replace SaverLok body (2) as needed.
To remove:
1. Clean front wrench of all pipe and tooling.
2. Close front wrench.
3. Position the carriage so that the SaverLok collar (3) can be clamped into the rear wrenchClamp rear
wrench on SaverLok collar.
4. Rotate spindle counterclockwise to unthread collar. Remove collar from system and set aside for later
use.
5. Remove SaverLok body from SaverLok connection (1).
• If parts are clean and dry, pull SaverLok body free of SaverLok connection by hand.
• If the parts are not clean and dry, reposition carriage to clamp SaverLok body in rear wrench and
thrust carriage back to pull SaverLok body free from connection.
6. Turn off engine.
NOTICE: Clamping front wrench on SaverLok
nose will damage the threads and impede
disassembly.
IMPORTANT: Unit may not build enough torque to break out the SaverLok body unless both
wrenches are closed.
j59om058w.eps
1
2
3
