Controls - 52 JT40/JT40 All Terrain Operator’s Manual
Right Control Console
10. Rear home/stop
indicator
Indicates when the
carriage has reached
the rear home/stop
indicator.
• Yellow background: Carriage is
approaching the rear home
position.
• Green background: Carriage
has reached the rear home
position.
• Red background: Carriage is in
the rear stop position.
11. Carriage indicator Animated display of the
movement of the carriage and
outer and inner (AT only)
pipe.
12. Tool joint position
indicator
Displays the current position
of the SaverLok
®
and pipe
tool joints.
Item Description Notes
R
