DMP Electronics XT Series User Manual

Digital Monitoring Products, Inc. | XT30 and XT50 User Guide 3
GET TO KNOW YOUR SYSTEM
Control Panel
The control panel acts as your system’s brain. It communicates with the keypad
and all the other system devices throughout the building.
Keypad
The keypad allows you to control your system from one place. You can use it
to arm and disarm your system, add user codes, verify alarms, and many other
functions.
Prox Key
A prox key is an impact resistant credential that fits on a standard key ring. It
allows for codeless arming, disarming, and door access when it is presented to a
reader.
Sensor
Sensors are small devices that monitor motion, temperature, flooding, breaking
glass, and know when windows and doors have been opened.
Key Fob Remote
Depending on how your key fob remote is set up, it provides an easy way to arm
and disarm your system or send a panic alarm.
Siren
The siren emits sound when your system goes into alarm.
Smoke and Carbon Monoxide (CO) Detector
These detectors notify you when smoke or carbon monoxide is present. Some
detectors have an integrated synchronized sounder. If they are installed in groups,
they will all sound simultaneously.
Your system may not include all of the equipment and functions found in this guide.
FRI 2:52 PM
1 2 3 4
5 6 7 8
9 0 CMD
A
C
B
D
F
E
G
I
H
J
L
K
V
X
W
S
U
T
P
R
Q
M
O
N
Y
Z
E
N
T
E
R
B
A
C
K
TODAY
82
98 77
CURRENT
HI LO
98 77
HI LO
Panic
Chime
Reset
Favorites
DISARMED
TUESDAY
J3
Phone Line
Outputs
J11
1
2
3
4
J1
Ethernet
J16
Reset
J20
Wireless
Antenna
connection
(XT50 only)
J7 RJ
Supervision
J24 Celllular
header for
263G
connection
J19 Celllular
Antenna
connection
J18
Load
Programming
J8
OVC LED
Power
LED
XMIT
TX RX
Wireless LEDs
RCV
