F.1 Concentration Log Files (CONCHH.CSV)
Concentration log files log information to the MicroSD card (if installed). A sample alarm file
is shown in figure F.2 The columns show: Date/Time, Gas Concentration, Alarm Level 1,
Alarm Level 2, Pump current (for filter diagnosis), DiagnosticFlags, two diagnostic values
and the time since the pump started in seconds
Date/Time Conc
Alarm
Level
1
Alarm
Level
2
Pump
Current
Diagnostic
Flags
Diag
Value
1
Diag
Value 2
Cycle
Time
3/15/2012 17:33 0 500 1000 36 16 2851 2849 4
3/15/2012 17:33 0 500 1000 41 0 2851 2849 8
3/15/2012 17:33 0 500 1000 44 0 2851 2851 12
3/15/2012 17:33 0 500 1000 46 0 2851 2848 16
3/15/2012 17:33 0 500 1000 47 0 2851 2845 20
3/15/2012 17:33 0 500 1000 47 0 2851 2851 24
3/15/2012 17:33 0 500 1000 48 0 2851 2848 28
3/15/2012 17:33 0 500 1000 49 0 2851 2848 32
3/15/2012 17:33 0 500 1000 49 0 2851 2847 36
Figure F.2
F.2 Event Log Files (EVENTHH.CSV)
New fault and alarm events are stored in internal memory and copied to the MicroSD card (if
installed) A sample event log as stored on the MicroSD is shown in figure F.3. The columns
show: Date/Time, Event Description, Diagnostic Value 1, On/Off, and Diagnostic Value 2
The Events are listed in Appendix D.
Date Time Event
Diagnostic
Value 1 On/Off
Diagnostic
Value 2
3/12/2012 10:44 Power On A 1 0
3/12/2012 10:44 Installer Update 2A 1 120301
3/12/2012 10:44 Installer Upd Comp 2B 1 120301
3/12/2012 10:45 Power Off B 1 0
Figure F.3
