Five volt sensor supply (primary)
Five volt sensor supply (secondary)
Fuel injectors
Fuel pump relay
Generator field driver (-)
Generator field driver (+)
Generator lamp (if equipped)
Idle air control (IAC) motor
Ignition coil
Leak detection pump (if equipped)
Malfunction indicator lamp (Check engine lamp).
Driven through CCD circuits.
Overdrive indicator lamp (if equipped)
Speed control vacuum solenoid
Speed control vent solenoid
Tachometer (if equipped). Driven through CCD
circuits.
Transmission convertor clutch circuit
Transmission 3–4 shift solenoid
Transmission relay
Transmission temperature lamp (if equipped)
Transmission variable force solenoid
MODES OF OPERATION
OPERATION
As input signals to the Powertrain Control Module
(PCM) change, the PCM adjusts its response to the
output devices. For example, the PCM must calculate
different injector pulse width and ignition timing for
idle than it does for wide open throttle (WOT).
The PCM will operate in two different modes:
Open Loop and Closed Loop.
During Open Loop modes, the PCM receives input
signals and responds only according to preset PCM
programming. Input from the oxygen (O2S) sensors
is not monitored during Open Loop modes.
During Closed Loop modes, the PCM will monitor
the oxygen (O2S) sensors input. This input indicates
to the PCM whether or not the calculated injector
pulse width results in the ideal air-fuel ratio. This
ratio is 14.7 parts air-to-1 part fuel. By monitoring
the exhaust oxygen content through the O2S sensor,
the PCM can fine tune the injector pulse width. This
is done to achieve optimum fuel economy combined
with low emission engine performance.
The fuel injection system has the following modes
of operation:
Ignition switch ON
Engine start-up (crank)
Engine warm-up
Idle
Cruise
Acceleration
Deceleration
Wide open throttle (WOT)
Ignition switch OFF
The ignition switch On, engine start-up (crank),
engine warm-up, acceleration, deceleration and wide
open throttle modes are Open Loop modes. The idle
and cruise modes, (with the engine at operating tem-
perature) are Closed Loop modes.
IGNITION SWITCH (KEY-ON) MODE
This is an Open Loop mode. When the fuel system
is activated by the ignition switch, the following
actions occur:
The PCM pre-positions the idle air control (IAC)
motor.
The PCM determines atmospheric air pressure
from the MAP sensor input to determine basic fuel
strategy.
The PCM monitors the engine coolant tempera-
ture sensor input. The PCM modifies fuel strategy
based on this input.
Intake manifold air temperature sensor input is
monitored.
Throttle position sensor (TPS) is monitored.
The auto shutdown (ASD) relay is energized by
the PCM for approximately three seconds.
The fuel pump is energized through the fuel
pump relay by the PCM. The fuel pump will operate
for approximately three seconds unless the engine is
operating or the starter motor is engaged.
The O2S sensor heater element is energized via
the ASD relay. The O2S sensor input is not used by
the PCM to calibrate air-fuel ratio during this mode
of operation.
ENGINE START-UP MODE
This is an Open Loop mode. The following actions
occur when the starter motor is engaged.
The PCM receives inputs from:
Battery voltage
Engine coolant temperature sensor
Crankshaft position sensor
Intake manifold air temperature sensor
Manifold absolute pressure (MAP) sensor
Throttle position sensor (TPS)
Starter motor relay
Camshaft position sensor signal
The PCM monitors the crankshaft position sensor.
If the PCM does not receive a crankshaft position
sensor signal within 3 seconds of cranking the
engine, it will shut down the fuel injection system.
The fuel pump is activated by the PCM through
the fuel pump relay.
Voltage is applied to the fuel injectors with the
ASD relay via the PCM. The PCM will then control
the injection sequence and injector pulse width by
turning the ground circuit to each individual injector
on and off.
DN FUEL SYSTEM 14 - 29
DESCRIPTION AND OPERATION (Continued)
