ParaMon-Pro X instruction manual DOC.60391-01/21
While the above current represents the actual current consumption of the tool, current
command refers to target current to control.
In other words, if current and current command are set and compared in two channels,
it is able to compare and analyze both actual and target current values.
Represents changes in snug angle by time (ms).
For more information about snug angle, refer to ‘8.1 Fastening → Snug torque’.
Applicable to channel 1 only
In upper data sources, x-axis all represents time (ms).
In torque and angle, x-axis is angle, representing torque changes by angle.
Applicable to channel 2 only; disables channel 2
A. Press [Setting] and set the graph output.
In the START state, the SETTING button is disabled.
Sets the source data of channel #1
Sets the source data of channel #2
Sets a direction of graph output
Sets the sampling interval of source data
Since a graph can represent up to 200 points per channel, precision increases as
sampling interval decreases. However, time slot is reduced.
The maximum time sloths by channel according to sampling settings are as follows:
- 5ms x 200 = 1,000 ms (1 sec)
- 10ms x 200 = 2,000 ms (2 sec)
- 15ms x 200 = 3,000 ms (3 sec)
- 30ms x 200 = 6,000 ms (6 sec)
If operating time exceeds the above level, the latest data only appear.
B. Press [Start] and enable graph output.
C. Press [Clear] and reset data output.
