11.2.1 Input
Unlike output, input is not able to allocate system functions in a redundant manner.
The system functions already allocated to other parts are enabled as shown in the figure.
NO.
Category
Description
1
Job selection 1-8
Able to load jobs through external input under the ‘With job’ mode.
For more information, refer to ‘11.1 Operation → D. Job selection type via input’.
2
Skip
Able to skip the next screw or move to the next step if necessary during job execution.
3
Back
Able to return back to the previous screw if necessary during job execution.
Valid in the fastening step only; unable to return back to the previous step.
4
Reset step
Resets the current step.
5
Reset job
Resets the current job.
6
Next job
Executes the next job if it exists on the job list.
7
Previous job
Executes the previous job if it exists on the job list.
8
Alarm reset
Clears ParaMon-Pro X alarm.
