Maintenance Section
-147-
Information - correlation between Symbol and message (Display)
As shown in the table below, for your information, we provide Information about correlation between Symbol
and message (Display)
No State SYMBOL Lamp Message on the Display
1
Request Service
Regeneration
-
Recommend Regeneration in 10hr
Need Engine Warm up
2 ON
Should Do Regeneration in 5hr
Need Engine Warm up
3 Blink
Must Do Regeneration Immediately
Need Engine Warm up
4
Progressing Passive
Regeneration
Progressing Service
Regeneration
ON Hot Exhaust Gas
5
Service Regeneration
Preparation Lamp
ON Warming up for DPF Regeneration
6 Under Regeneration ON
Cleaning Aftertreatment
DO NOT STOP ENGINE
7 DPF Regeneration Finish - Regeneration completed
8
DPF Regeneration inhibit
switch ON
ON Regeneration is inhibited
