TMS(Lin-Q) (Option)
Safety Precautions
This information is intended to protect the safety and
property of the user.
Before using the TMS (LIN-Q) terminal, make sure to
read the user manual carefully and familiarize
yourself with the contents.
Operating Environment
•
The TMS (LIN-Q) terminal has an operating
voltage of DC 9 V – 34 V.
•
Make sure to use it within the specified
temperature range.
Installation and Wiring
•
The installation and wiring procedures require
professional expertise. Consult a professional
technician for assistance with installing the
product. Improper installation or wiring may cause
a fire and/or malfunction.
•
Perform the installation and wiring in a place free
of moisture. Installing the product in a place with
the risk of water or rain splashing on it or with
significant amounts of dust or dirt may cause
malfunctions and accidents.
•
Use the specified cables and parts.
•
When installing the product on the ceiling of the
machine or in places with severe vibrations, take
care to ensure that it does not fall and make sure
that it is secured properly.
•
Do not block any vents or heat sinks. Doing so
may cause a fire.
Precautions for Using the Product
•
Avoid operating the terminal while the vehicle is
running; otherwise, an accident may occur. Stop
the machine in a safe place before operating the
terminal.
•
Do not disassemble or modify the terminal without
permission. Unauthorized disassembly and
modification may cause a malfunction and void
the warranty for after-sales service.
Basic TMS
Lift Control knob
The TMS (LIN-Q) terminal is mounted on the forklift
to monitor the driving and operating state of the
vehicle.
To register and use the product, visit the Lin-Q
website or contact an administrator.
System Schematic Drawing
The terminal uses LTE, Wi-Fi communications
(providing each terminal) and is an IoT terminal which
can be used anywhere in the world.
