General Section
-33-
Specifications
Characteristics
1.1 Manufacturer Doosan
1.2 Model designation D20S-9
1.3 Drive: Diesel, Gasoline, LP Diesel
1.4 Operator type: Hand, Pedestrian, Standing, Seated, Order-picker Seated
1.5 Load Capacity Q kg 2,000
1.6 Load Center c mm 500
1.8 Load Distance: Center of Driveaxle to fork x mm 480
1.9 Wheelbase y mm 1,700
Weight
2.1 Service weight kg 3,830
2.2 Axle Loading, Laden Front/Rear kg 4,977/853
2.3 Axle Loading, Unladen Front/Rear kg 1,825/2,005
Tyres
3.1 Tyres: pneumatic (P), superelastic (SE), cushion (C) P
3.2 Tyre size, Front 7.00x15-12
3.3 Tyre size, Reat 6.50x10-10
3.5
Wheels, number Front/Rear
(x = driven wheels)
2/2
3.6 Tread, Front b
11
mm 975
3.7 Tread, Rear b
12
mm 990
Dimensions
4.1 Tilt of Mast/Fork carriage Forward/Backward / ° 6/10
4.2 Height, Mast lowered h
1
mm 2,190
4.3 Free Lift h
2
mm 147
4.4 Lift h
3
mm 3,230
4.5 Height, Mast Extended h
4
mm 4,490
4.7 Height of Overhead Guard(Cabin) h
6
mm 2,183
4.8 Height of Seat h
7
mm 1,026
4.19 Overall Length l
1
mm 3,624
4.20 Length to Forkface l
2
mm 2,574
4.21 Overall Width b
1
/b
2
mm 1,170
4.22 Fork Dimensions s/e/l mm 40x100x1,050
4.23 Fork carriage ISO 2328, class/type A,B II
4.24 Fork carriage width b
3
mm 1,103
4.31 Ground Clearance, laden, below mast m
1
mm 115
4.32 Ground Clearance, center of wheelbase m
2
mm 143
4.34.1 Aisle withd for pallets 1,000 x 1,200 crossways A
st
mm 3,910
4.34.2 Aisle width for pallets 800 x 1,200 lengthways A
st
mm 4,110
4.35 Turning Radius W
a
mm 2,230
4.36 Internal Turning Radius b
13
mm 640
Performance data
5.1 Travel Speed, Laden/Unladen km/h 20/21
5.2 Lift Speed, Laden/Unladen m/s 0.61/0.65
5.3 Lowering Speed, Laden/Unladen m/s 0.51/0.45
5.5
Drawbar pull, Laden/Unladen
(@ 1.6km/h)
N 17,780/17,500
5.6 Max. Drawbar pull, Laden/Unladen N 19,860/19,400
5.7
Gradeability, Laden/Unladen
(@ 1.6km/h)
% 33.6/55.2
5.8 Max. Gradeability, Laden/Unladen % 38.1/63.5
