General Section
-34-
5.10 Service Brake foot/hyd
Combustion Engine
7.1 Engine Manufacturer/type DI/DM02VA STAGE-5
7.2 Engine power according to DIN ISO1585 kW 45.6
7.3 Rated Speed min
-1
2,200
7.3.1 Torque at 1/min N•m 300Nm / 1,200~1,400
7.4 Number of Cylinders/Displacement -/cm
3
4/2,392
7.5 Fuel Consumption according to VDI Cycle l/h or kg/h 2.8
7.10 Battery Voltage/normal capacity V/Ah 12/110
Addition
Data
10.1 Operating pressure for attachments bar 156
10.2 Oil volume for attachments l/min 76.5
10.4 Fuel Tank Capacity l 58
10.7 Sound level at the driver's ear according to EN 12 053 dB(A) 75
