Maintenance Section
-155-
Replacing Engine Oil
• Special tools
Figure Part No. / Name
Oil /Filter Cap
110910-00628
• Tightening Torque
Part Tightening Torque
Drain plug 3 kgf
•
m
• Oil capacity
Engine
Model
Engine oil capacity (L).
Inside the oil pan
Total
Maximum Minimum
D24 8.6 4.5 9.2
1. Place a container under the engine for collecting
drained oil.
2. Open the drain plug (1) and drain the engine oil.
Remove the oil refill cap (2).
Using the oil filter cap (110910-00628), replace the
oil filter (1).
3. Use the genuine engine oil approved /
recommended by the manufacturer.
4. Close the oil refill cap (2) and install the oil level
gauge.
5. Run the engine for 5 minutes to check engine
oil leak, and engine oil level with the oil level
gauge.
NOTICE
Servicing of the engine oil and oil filter element will
largely affect the engine performance as well as the
engine life.
Engine oil and filter element must be changed after
the first 50 hours.
