Doosan D35C-9 User Manual

General Section
-38-
5.10 Service Brake foot/hyd
Combustion Engine
7.1 Engine Manufacturer/type DI/DM02P De-tier (T4F)
7.2 Engine power according to DIN ISO1585 hp(N) 62 (45.6)
7.3 Rated Speed min
-1
2,200
7.3.1 Torque at 1/min ft•lbs(N•m)
203.5 ft•lbs
(276 Nm /1,500)
7.4 Number of Cylinders/Displacement -/cc(-/cm
3
) 4/2,392
7.5 Fuel Consumption according to VDI Cycle
gal/h or lb/h
(l/h or kg/h)
0.74 (2.8)
7.10 Battery Voltage/normal capacity V/Ah 12/80
Addition
Data
10.1 Operating pressure for attachments Psi (bar) 2,262.5 (156)
10.2 Oil volume for attachments gpm (l/min) 20.2 (76.5)
10.4 Fuel Tank Capacity gal(l) 15.3 (58)
10.7 Sound level at the driver's ear according to EN 12 053 dB(A) 75

Doosan D35C-9 Specifications

General

Brand	Doosan
Model	D35C-9
Category	Forklifts
Language	English
