Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
107
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Filter Pressure Switch
Activated
%IX0.06
ON
C02 Input Function -- Side Door Closed Proximity Switch (Body Input %IX0.04)
This circuit monitors the ON/OFF status of the Side Door Closed Proximity Switch. The input is ON when
the side door is closed.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Side Door Proximity Switch
Activated
%IX0.04
ON
C03 Input Function -- Tailgate Closed Proximity Switch (Body Input %IX0.00)
This circuit monitors the ON/OFF status of the Tailgate Closed Proximity Switch. The input is ON when
the Tailgate is closed.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Closed Proximity Switch
Activated
%IX0.00
ON
C04 Input Function – Lift Below Transit Proximity Switch (Body Input %IX0.01)
This circuit monitors the ON/OFF status of the Lift Below Transit Proximity Switch. The input is ON when the arm is in the
Lowered position. NOT USED.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
NOT USED. FUTURE EXPANSION
