Body Controller Software
106
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Pump On
Activated
N/A
ON
B
Neutral Signal
Activated
%IX0.10
ON (See Note Below)
C
Throttle Advance Output
Deactivated
%QX0.10
OFF
Note: With condition ‘A’ true, Condition (B AND C) will activate the Throttle Limit output.
B04 Output Function – WARBLE Alarm (In Cab Output %QX128.09)
This output function controls the Warble Alarm.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Tailgate Closed Prox. Switch
Deactivated
%IX0.00
OFF
Note: Condition ‘A’ true will activate the Warble Alarm output.
B05 Output Function – Hopper Flood Light (In Cab Output %QX128.10)
This output function controls the Hopper Flood Light. Here CAN control is used to turn ON/OFF the
Hopper Light Circuit, either from Street side or from the Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or
Component
Status
I/O Address
Status
A
Hopper Light Switch
Activated
CAN
ON
Note: With condition (A) true the Hopper Flood Light output will activate.
4.03: Standard Body Input Functions
C01 Input Function – Oil Filter Pressure Switch (Body Input %IX0.06)
This circuit monitors the ON/OFF status of the Oil Filter Pressure Switch. The input is OFF when the
filter is in bypass. The input is ON when the filter is in normal operation i.e. not in bypass.
