Body Controller Software
110
D03 Output Function – Tailgate Lock Solenoid (Body Output %QX0.04)
This output function controls the Tailgate Lock output circuit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Tailgate Lock Push Button
Activated
CAN
ON
B
Panel Selector Switch
Activated
%IX0.09
ON
C
Road Speed OK
Activated
N/A
ON (see Note below)
D
Tailgate Locked Prox.
Deactivated
%IX0.02
OFF
E
and Pump On
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Tailgate Lock switch either from Street side or
from Curb side panel. With ((A AND B AND C AND D)) true, Condition ‘E’ will activate the Tailgate Lock output. For
condition ‘C’ to be true, Road Speed value should be less than ‘5’ mph.
D04 Output Function – Tailgate Unlock Solenoid (Body Output %QX0.07)
This output function controls the Tailgate Unlock output circuit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Tailgate Un Lock Push Button
Activated
CAN
ON
B
Panel Selector Switch
Activated
%IX0.09
ON
C
Road Speed OK
Activated
N/A
ON (see Note below)
D
Tailgate Unlocked Prox.
Activated
N/A
ON
D
and Pump On
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Tailgate Unlock switch either from Street side
or from Curb side panel. With conditions ((A AND B AND C AND D) true, Condition ‘E’ will activate the Tailgate Unlock
output. For condition ‘C’ to be true, Road Speed value should be less than ‘5’ mph.
D05 Output Function – Back Up Alarm (Body Output %QX128.12)
This output function controls the Back Up Alarm output.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
