Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
111
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Tailgate Closed Prox.
Deactivated
%IX0.00
ON
B
Tailgate Locked Prox.
Deactivated
%IX0.00
ON
Note: If Tailgate is not closed OR if Tailgate is not Locked i.e. if condition (A OR B) is true, then Back Up Alarm is
activated.
D06 Output Function – Arms Up PWM control (Body Output %QX0.04)
This output function controls the Arms up PWM Control output circuit.
The Arms up PWM control circuit either with the Auto Lift signal (fixed speed) or with the Manual
lift signal (variable speed) will control the speed of Arm Up movement when operated.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Auto Lift Enable Switch
Activated
N/A
ON
B
Pump On
Activated
N/A
ON
C
Arms up Interlock
Deactivated
N/A
OFF
D
Aux Controls Enable
Activated
N/A
ON (Manual Control – Var. speed)
E
Aux Arms Raise
Activated
N/A
ON (Manual Control – Var. speed)
F
Sensor Failure
Deactivated
N/A
OFF
G
Raise Arms
Activated
N/A
ON
Note: The Arms Valve PWM output provides flow to the hydraulic hoses on the arms cylinder. This flow, when combined
with the activation of Arms up function, will move the Arms up (with fixed or variable speed). The flow setting of this valve
is adjustable using the Insight diagnostic display.
D07 Output Function – Arms Down PWM control (Body Output %QX0.05)
This output function controls the Arms down PWM Control output circuit. The Arms down PWM control circuit either with
the Auto Lift signal (fixed speed) or with the Manual lift signal (variable speed) will control the speed of Arm down
movement when operated.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Auto Lift Enable Switch
Activated
N/A
ON
B
Pump On
Activated
N/A
ON
