Body Controller Software
112
Condition
Function or Component
Status
I/O Address
Status
C
Arms Down Interlock
Deactivated
N/A
OFF
D
Aux Controls Enable
Activated
N/A
ON (Manual Control – Var. speed)
E
Aux Arms Lower
Activated
N/A
ON (Manual Control – Var. speed)
F
Sensor Failure
Deactivated
N/A
OFF
G
Lower Arms
Activated
N/A
ON
Note: The Arms Valve PWM output provides flow to the hydraulic hoses on the Arms cylinder. This flow, when combined
with the activation of Arms down function, will move the Arms down (with fixed or variable speed). The flow setting of this
valve is adjustable using the Insight diagnostic display.
D08 Output Function – Cab Protector Up Control (Body Output %QX0.03)
This function controls the Cab Protector up output. Not used.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
NOT USED
D09 Output Function – Cab Protector Down Control (Body Output %QX0.02)
This function controls the Cab Protector Down output. Not used.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
NOT USED
D10 Output Function – Allison PTO Enabled (Body Output %QX0.00)
This output function controls the Allison Power Take Off (PTO).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Pump Enable Push Button
Activated
CAN
ON
System Power Switch
Activated
%IX0.8
ON
