Dover HEIL Half/Pack Factor AFL - Page 119

Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
113
Condition
Function or Component
Status
I/O Address
Status
Side Door Prox. Switch
Activated
%IX0.4
ON
B
Road Speed
Activated
N/A
ON (see Note below)
C
Engine Speed
Activated
N/A
ON (see Note below)
D
Filter Bypass
Deactivated
N/A
OFF
E
Filter Pressure Switch
Activated
%IX0.6
ON
F
Low Oil Level Switch
Activated
%IX0.7
ON (see Note Below)
Note: With condition (A AND B AND C AND F) true, Condition (D OR E) will activate the Allison PTO pump.
For condition ‘B’ to be true, Road Speed value should be less than ‘15’ mph.
For condition ‘C’ to be true, Engine Speed value should be less than ‘900’ RPM.
Condition ‘F’ Low Oil Switch will be considered only during Calibration mode.
D11 Output Function – PTO-2 Pump (Body Output %QX0.09)
This output function controls the Power Take Off (PTO) Pump-2 output.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Pump Enable Push Button
Activated
CAN
ON
System Power Switch
Activated
%IX0.8
ON
Side Door Prox. Switch
Activated
%IX0.4
ON
B
Road Speed
Activated
N/A
ON (see Note below)
C
Engine Speed
Activated
N/A
ON (see Note below)
D
Filter Bypass
Deactivated
N/A
OFF
E
Filter Pressure Switch
Activated
%IX0.6
ON
F
Low Oil Level Switch
Activated
%IX0.7
ON (see Note Below)
Note: With condition (A AND B AND C AND F) true, Condition (D OR E) will activate the PTO-2 pump.
For condition ‘B’ to be true, Road Speed value should be less than ‘15’ mph.
For condition ‘C’ to be true, Engine Speed value should be less than ‘900’ RPM.
Condition ‘F’ Low Oil Switch will be considered only during Calibration mode.
D12 Output Function – PTO-1 Pump (Body Output %QX0.08)
This output function controls the Power Take Off (PTO) Pump-1 output.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
