Body Controller Software
115
Condition
Function or Component
Status
I/O Address
Status
NOT USED
D15 Output Function – Curotto - Carry Can Up (Body Output %QX0.06)
This function controls the Curotto - Carry Can Up signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Panel Selector Switch
Activated
%IX0.09
ON
and Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
B
Carry Can Up
Activated
CAN
ON (Refer Sec. I26)
and Carry Can Auxiliary Enable Switch
Activated
CAN
ON
C
and Autolift Enable Switch
Activated
CAN
ON
D
Bayne Up
Activated
N/A
ON
E
and Scale Alarm 2
Deactivated
%IX128.2
OFF (See Section A04)
F
Pump On
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Carry Can Up switch either from Street side
or from Curb side panel.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present or if Bayne Up control is enabled.
With Conditions ((A OR B) AND C) true OR ‘D’ true, condition (E AND F) will activate the Carry Can Up Output signal either
in Auxiliary control mode or Non-Auxiliary control mode.
D16 Output Function – Curotto - Carry Can Down (Body Output %QX0.05)
This function controls the Curotto - Carry Can Down signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Panel Selector Switch
Activated
%IX0.09
ON
and Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
B
Carry Can Down
Activated
CAN
ON (Refer Sec. I27)
and Carry Can Auxiliary Enable Switch
Activated
CAN
ON
C
Autolift Enable Switch
Activated
CAN
ON
