Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
116
and Scale Alarm 2
Deactivated
%IX128.2
OFF (See Section A04)
and Pump On
Activated
N/A
ON
D
Bayne Down
Activated
N/A
ON
Pump On
Activated
N/A
ON
E
Stow Can
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Carry Can Down switch either from Street
side or from Curb side panel.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present or if Bayne Down control is enabled.
With Conditions (A OR B) true, Condition (C OR D OR E) true will activate the Carry Can Down Output either in Auxiliary
control mode or Non-Auxiliary control mode.
D17 Output Function – Curotto - Carry Can In (Body Output %QX0.04)
This function controls the Curotto - Carry Can In signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Panel Selector Switch
Activated
%IX0.09
ON
and Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
B
Carry Can In
Activated
CAN
ON
and Carry Can Auxiliary Enable Switch
Activated
CAN
ON
C
and Autolift Enable Switch
Activated
CAN
ON
D
and Pump On
Activated
N/A
ON
E
and Scale Alarm 2
Deactivated
%IX128.2
OFF (See Section A04)
F
Pump On
Activated
N/A
ON
and Stow Can
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Carry Can In switch either from Street side or
from Curb side panel.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present.
With Conditions (A OR B) true, Condition (C AND D AND E) true will activate the Curotto Carry Can In signal either in
Auxiliary control mode or Non-Auxiliary control mode.
The Carry Can In signal is also activated with Condition ‘F’ true, which is a Stow Can signal.
D18 Output Function – Curotto - Carry Can Out (Body Output %QX0.03)
This function controls the Curotto - Carry Can out signal.
Condition
Modifiable Parameters
Default Setting
