Dover HEIL Half/Pack Factor AFL - Page 123

Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
117
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Panel Selector Switch
Activated
%IX0.09
ON
and Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
B
Carry Can Out
Activated
CAN
ON
and Carry Can Auxiliary Enable Switch
Activated
CAN
ON
C
and Autolift Enable Switch
Activated
CAN
ON
D
and Pump On
Activated
N/A
ON
E
and Scale Alarm 2
Deactivated
%IX128.2
OFF (See Section A04)
Note: This signal is energized using a CAN based control by energizing the Carry Can Out switch either from Street side or
from Curb side panel.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present.
With Condition (A OR B) true, Condition (C AND D AND E) true will activate the Curotto Carry Can Out signal in either
Auxiliary control mode or Non-Auxiliary control mode.
D19 Output Function – Curotto - Carry Can Grab (Body Output %QX0.02)
This function controls the Curotto - Carry Can Grabber signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Carry Can Auxiliary Enable Switch
Activated
CAN
ON
Carry Can Grab
Activated
CAN
ON (Refer Sec. I24)
B
Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
Joystick Right Button
Activated
JOYSTICK
ON
C
Autolift Enable Switch
Activated
CAN
ON
D
and Scale Alarm 2
Deactivated
%IX128.4
OFF (See Section
A04)
E
and Pump On
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Carry Can Grab switch.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present.
With Conditions (C AND D AND E) true, condition (A OR B) will activate the Carry Can Grabber output either in Auxiliary
control mode or Non-Auxiliary control mode.
