Body Controller Software
118
D20 Output Function – Curotto - Carry Can Release (Body Output %QX0.01)
This function controls the Curotto - Carry Can Release signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Carry Can Auxiliary Enable Switch
Activated
CAN
ON
Carry Can Release
Activated
CAN
ON (Refer Sec. I25)
B
Carry Can Auxiliary Enable Switch
Deactivated
CAN
OFF
Joystick Left Button
Activated
JOYSTICK
ON
C
Autolift Enable Switch
Activated
CAN
ON
D
and Scale Alarm 2
Deactivated
%IX128.4
OFF (See Section
A04)
E
and Pump On
Activated
N/A
ON
F
and Pump On
Activated
N/A
ON
and Stow Can
Activated
N/A
ON
Note: This signal is energized using a CAN based control by energizing the Carry Can Release switch.
The Curotto system is operated in Carry Can mode with Arm below 25 Deg. and Scale Alarm 2 is deactivated i.e. Over
Weight condition is not present.
With Condition (A OR B)) true, Condition (C AND D AND E) true, will activate the Curotto Carry Can Release signal either
from Auxiliary control mode or from Non-Auxiliary control mode.
The Carry Can Release signal is also activated with Condition ‘F’ true, which is a Stow Can signal.
