D21 Output Function – Tailgate Enable PWM control (Body Output %QX0.14)
This output function controls the Tailgate PWM control output circuit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or
Component
Status
I/O Address
Status
A
Tailgate Down
Activated
%QX0.03
ON
or Tailgate Up
Activated
%QX0.02
ON
or Tailgate Lock
Activated
%QX0.04
ON
or Tailgate Unlock
Activated
%QX0.07
ON
or Top Door Open
Activated
%QX0.05
ON
or Top Door Close
Activated
%QX0.06
ON
B
and Pump On
Activated
N/A
ON
Note: The Tailgate PWM output provides flow to the Tailgate hydraulic valve assembly. This flow, when combined with
activation of a Tailgate function, will move the Tailgate Up, Down, Lock, Unlock, Top Door Open or Top Door Close.
With condition ‘B’ true, Tailgate Valve PWM output will activate any of the output in condition ‘A’.
