Body Controller Software

140

Section 5: Special Features

5.01: Auto Pack Mode

Auto Pack is a standard feature on all CORTEX controlled FEL (Front End Loader) products. While in Auto Pack the

Packer will complete its cycle automatically with a momentary activation of the Packer Extend push button.

5.02: Select-O-Pack

Select-O-Pack is an option for Commercial FEL products and is standard on Residential FEL products.

If the Select-O-Pack switch is enabled, then an Auto pack cycle will begin when the Arms reach a pre-defined position

during a lower action.

For Commercial or Non-Curotto Can units that predefined location is when the Arms above Height proximity switch

activates during a down motion, while on Curotto Can units it activates when the Arms read the bottom of the cycle.

5.03: Travel Position

When the Travel position switch is enabled pressing Packer Extend will Extend Packer to Travel position and stop. The

indication will flash while moving and turn solid when at the Travel position. To return to the home turn OFF Travel position

switch and hold retract. Travel position functionality is available only in manual mode

5.04: INSIGHT Display Functionality

CORTEX32 Controller uses a hand held device (INSIGHT) for displaying the current status of Input / Output, Engine

speed, Temperatures etc., and can be used to SET / RESET any particular Input / Output bit. This can also be used for

configuring or selecting different options in CORTEX32 controller.

This display has provision of connecting 1-Input (Digital or Analog), 1-Ouput terminal to it. Also, a Analog video input which

supports PAL/NTSC standard can also be connected to it.

Other features of this display are, it has an Integrated Buzzer and 2 sensors which can be used to monitor the Temperature

inside the housing.

There are 2 types of INSIGHT display devices used here for performing various operations as mentioned below:

A. INSIGHT Display (7“)

B. INSIGHT Display (12“)

5.04.01A: INSIGHT Display (7”) Operating Elements

INSIGHT Display (7”) :- Consists of 9 backlit function keys, Analogue video input, and a INSIGHT (Graphic) display

terminal as shown below:
