Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
162
Disabled Functions: Packer extend.
Fault Reset: Turn ON the pump.
Hydraulic Filter Is In Bypass (standard equipment)
If the hydraulic filter has been in bypass for more than 11 hours, then the diagnostic message will be displayed in the
Insight display.
Insight Display Illustration:
Indication: The Pump will only work for 3 minutes.
Disabled Functions: Pump
Fault Reset: Replace hydraulic oil filter.
Arms Raised Interlock and Overweight Alarm Active (standard equipment)
If the arms have been raised when the top door is not fully open or the packer is not fully retracted and the Packer/ Cab
protector switch has not been enabled / Scale Alarm-2 is enabled due to Overweight / PTO-1 or PTO-2 pump is ON,
then the diagnostic message will be displayed in the Insight display.
Insight Display Illustration:
