Body Controller Software
170
further.
Tailgate Unlocked and Road Speed High Interlock (standard equipment)
If the Tailgate is unlocked when the Road speed is greater than 10mph i.e. if the Tailgate is unlocked when the
unit is in motion, the diagnostic message will be displayed on the Insight display.
NOTE: Tailgate operation can be performed only when the Road speed is less than 5mph.
Insight Display Illustration:
Indication: A. Tailgate Unlocked.
Disabled Functions: None.
Fault Reset: Close and Lock the Tailgate or repair the faulty Tailgate Locked proximity switch to proceed
further.
Filter Bypass Switch Fault (standard equipment)
If the CORTEX Controller has lost the signal from the filter pressure switch while neither hydraulic pump was in
operation the diagnostic message will be displayed in the Insight display. This is recognized as a fault because
there should be no hydraulic pressure to bypass the filter under this condition.
Insight Display Illustration:
