General Information
20
TORQUE FOR HYDRAULIC TUBES AND FITTINGS (CONTINUED)
SPLIT- FLANGE (HALF CLAMP) CONNECTORS (CODE 62)
SET WRENCH TO
NOMINAL
TUBE OD
BOLT SIZE
BOLT TORQUE [FT-
LBS]
BOLT TORQUE [IN-LBS]
ALUMINUM FT-LBS [IN-
LBS]
1/2"
5/16-18 x 1.25
17 ft-lbs.
200 in-lbs.
12 [130]
3/4"
3/8-16 x 1.25
30 ft-lbs.
360 in-lbs.
20 [240]
1"
3/8-16 x 1.25
46 ft-lbs.
550 in-lbs.
30 [360]
1-1/4"
1/2-13 x 1.75
69 ft-lbs.
830 in-lbs.
45 [540]
1-1/2"
5/8-11 x 2.25
125 ft-lbs.
1500 in-lbs.
82 [980]
2"
3/4-10 x 2.75
209 ft-lbs.
2510 in-lbs.
136 [1640]
