Dover Wayne Select S1 User Manual

W2940305 Rev 07 8/2019 Dover Fueling Solutions 85
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.05 Flash selected unit price display after 8s
blanks 0s
1=No flash
2=Flash until flow
3=Flash always
1
.06 Suppress display of leading zeros in normal
mode
1=Yes
2=No
1
.07 Totals and totalizers amount display digits
right of the decimal point, 0-4
2
.08 Totals and totalizers volume display digits
right of the decimal point, 0-4
0
.09 Display functionality
0=Normal sale display
1=Fleet volume display (2
nd
row)
2=Fleet volume display (1
st
row-top)
1
F15 Dispenser Annunciator
Configuration
.00 Beep annunciator on any button push
1=Yes
2=No
1
.01 Beep annunciator on physical nozzle lift
1=Yes
2=No
1
.02 Repeat annunciator beep if physical nozzle
is out and push-to-start or grade select is not
satisfied
1=Yes
2=No
1
.03 Beep annunciator once for each eights,
blanks, and zeros
1=Yes
2=No
1
.04 Authorization alert (prompt cust to press
payment key)
0=Disabled
1=Beep & flash unit price displays after
product selected but not authorized
0
.05 Beep until nozzle returned
0=Disabled
01-20=Beep if nozzle out after filling (10-200
seconds, setting x10)
21-40=Beep if nozzle out after filling (110-
300 seconds, setting x10+100)
0
F16 Pulser Configuration .00 Measurement mode
1=Liters
2=Gallons
3=Imperial gallons
2
.01 Pulser reverse pulse hysteresis, 1-64 10
.02 Reserved
.03 Reverse pulse limit (after hysteresis) on an
idle/unused pulser, 1-255
80
.04 Meter type
1=WIP
2=PPM w/ LC meter
3=PPM w/ E85 meter
4=xFlo, 5=LC & iMeter combo
1 (2 for UHC, 4 for
E85 using xFlo)
F17 Dispenser Limits
Configuration
.00 Max. # of pulse errors on an in-use pulser (in
a transaction), 1-99
10 (50 for UHC)
.01 Max. # of pulse errors on an idle/unused
pulser, 1-99
80
