Dover Wayne Select S1 User Manual

94 Dover Fueling Solutions W2940305 Rev 07 8/2019
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.01 Blink rate for SW/LED 1
2-20=Blink rate (0.2-2.0 seconds)
10
.02 Blink rate for SW/LED 2
2-20=Blink rate (0.2-2.0 seconds)
10
.03 Blink rate for SW/LED 3
2-20=Blink rate (0.2-2.0 seconds)
10
.04 Blink rate for SW/LED 4
2-20=Blink rate (0.2-2.0 seconds)
10
.05 Blink rate for SW/LED 5
2-20=Blink rate (0.2-2.0 seconds)
10
F67 DEF Control
Configuration
.00 Upper Door Switch Input Side A 0
.01 Upper Door Switch Input Side B 0
.02 Lower Door Actuator Open Signal Output
Side A
0=Not used
1-10=Corresponding valve output signal
0
.03 Lower Door Actuator Open Signal Output
Side B
0=Not used
1-10=Corresponding valve output signal
0
.04 Lower Door Actuator Close Signal Output
Side A
0=Not used
1-10=Corresponding valve output signal
0
.05 Lower Door Actuator Close Signal Output
Side B
0=Not used
1-10=Corresponding valve output signal
0
.06 Low Temperature Signal Input Side A
0=Not used
1-4=Side A Nozzle 1-4
5-8=Side B nozzle 1-4
0
.07 Low Temperature Signal Input Side B
0=Not used
1-4=Side A Nozzle 1-4
5-8=Side B nozzle 1-4
0
F68 Additive Configuration .00 Display Current Tank Volume in Liters 0.0
.01-.07 Number of Turns per Liter by Logical Nozzle 0
.08 Additive Calibration Options
0=No calibration
1=Additive calibration Side 1 only
2=Additive calibration Side 2 only
3=Additive calibration both sides
4=No additive (allows W&M to measure
diesel only)
0
F95 Upload Dispenser
Function Data
Upload function data from dispenser (data
dump) to PC. This information is used to
report the current status of the dispenser
Requires laptop and service terminal.
F96 Upload Flash Memory Upload software code from dispenser to PC.
Requires laptop and service terminal
program.
F97 Upload Configuration Upload template file from PC to the
dispenser. Requires laptop and service
terminal program.
F98 Download Flash
Memory
Download software code to dispenser from a
file on PC. Requires laptop and service
terminal program.
F99 Download Configuration Download template to dispenser from a file
on PC. Requires laptop and service terminal
program.
