Dover Wayne Select S1 - F.3 Place Dispenser into Standalone Operation from Serial Mode

W2940305 Rev 07 8/2019 Dover Fueling Solutions 93
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
F42 Miscellaneous Config .00 Totals Display Mode
0=Display totalizers per meter
1=Display totalizers per logical nozzle
2=Display totals per meter
3=Display total per logical nozzle
4=Display WIP totalizers
0
F43 Meter Channel Config
M=Meter channel (1-4),
1=Meters 1 & 5
2=Meters 2 & 6
3=Meters 3 & 7
4=Meters 4 & 8
Use Setting F16 if
43.01-43.04=0
Used for dispensers with
mixed meter types
.0M Meter Type
0=No meter attached
1=iMeter
2=PPM w/ LC meter
3=PPM w/ E85 meter
4=xFlo meter
If F43.01 – F43.04 all equal “0”, use single
meter setting found in F16.00
0
or
1-4
.1M Pulser reverse pulse hysteresis, 1=-64 0 or 10
.2M Maximum number of pulse errors/reverse
pulses on an “In use” WIP in a transaction
(1-99)
0 or 10
or 50 (UHC)
.3M Reverse pulse limit (after hysteresis) on an
idle/unused meter (1-255)
0 or 80
.4M Liters-Suppress overflow of preset limit (0-99
cl)
0 or 5
.5M Liters-Preset/Prepay slow down volume delta
(5-399 cl)
0 or 57
.6M Liters-Forward pulse limit on idle/unused
WIP (1-99 cl)
0 or 95
.7M Gallons-Suppress overflow of preset limit (0-
99, 1=0.001 gals)
0 or 4
.8M Gallons-Preset/Prepay slow down volume
delta (2-999, 1=0.001 gallons)
0 or 150
.9M Gallons-Forward pulse limit on idle/unused
WIP (1-999, 1=0.001 gallons)
0 or 250
F50 ATC Configuration
(Canada Only)
N=Meter number (1-8)
.0N Temperature probe assignment
0 = none assigned (1-4)=probe assigned
.1N Product type assignment
0=Gasoline
1=Diesel
F56 Door Security .00 Door Security One Shot Enable
0=Not armed, 1=Armed, one-shot req’d to
disarm/reset
0 or 1
.01 Door Security Maintenance Mode Enable
0=Not armed, 1=Armed, maint mode entry
req’d to disarm/reset
0 or 1
.02 Bezel Switch Input
0=Disabled, 1-10 for nozzle switch
0 or 3
.03 Hydraulic Door Switch Input
0=Disabled, 1-10 for nozzle switch
0 or 7
.04 Alarm Output
0=Disabled, 1=Annunciator
0 or 1
.05 Alarm Output Time
0=Until 1 shot entry, 1-255=Number of
minutes to sound annunciator
0 or 10
.06 One Shot Response Entry Time
0=Wait forever, 1-255=Minutes to wait for
one-shot entry
0 or 2
.07 One Shot Door Access Time
1-255=Minutes to allow unarmed entry after
successful one-shot entry
0 or 1
F57 Product Select LED
Variable Blink Rate
.00 Product Select LED Variable Blink Rate
Enable
0=Variable blink rate not enabled
1=Variable blink rate enabled
0
