Dover Wayne Select S1 - F.2 Place Dispenser into Standalone Operation from Pulse Output

92 Dover Fueling Solutions W2940305 Rev 07 8/2019
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.8N Secondary valve type
1=On/off
2=Proportional
3=Two stage ASCO
4=Two stage Parker
.81=2
.9N Satellite Indicator (unit price display) .91=0
F39 Set Error Severity Level .xx xx=selected error number (.25 = price error)
0=Log Error
1=Sale Terminated
2=Semi-Fatal - Affected side of dispenser
closed
3=Fully Fatal - Both sides of dispenser
closed
4=Catastrophic - Both sides closed.
Requires power cycle to clear error.
5=Error detection disabled (price can be
zero)
5 (F39.25)
F41 Pulse Output
*Only available on fully-
populated version of the
Pulse Output Board
.01 Pulse output for nozzles on Side A
0=Not used
2=All nozzles Side A
12=Logical nozzle 1 only
0 2
.02 Pulse output for nozzles on Side B
0=Not used
2=All nozzles Side B
12=Logical nozzle 1 only
0 2
.03 Reset Complete, Side A Logical Nozzle 1
0=Not used
10=All nozzles Side A
11=Logical nozzle 1 only
0 10
.04 Reset Complete, Side B Logical Nozzle 1
0=Not used
10=All nozzles Side B
11= Logical nozzle 1 only
0 10
.05 Pulse Output, Side A Logical nozzle 2 *
0=Not used
12=Logical nozzle 2
0
.06 Pulse Output, Side B Logical Nozzle 2 *
0=Not used
12=Logical nozzle 2
0
.07 Reset Complete, Side A Logical Nozzle 2 *
0=Not used
11=Logical nozzle 2
0
.08 Reset Complete, Side B Logical Nozzle 2 *
0=Not used
11=Logical nozzle 2
0
.12 Call Signal, Side A Logical Nozzle 1
0=Not used
11=Enable to reset complete output
13=Enable to call output *
0
.13 Call Signal, Side B Logical Nozzle 1
0=Not used
11=Enable to reset complete output
13=Enable to call output *
0
.14 Call Signal, Side A Logical Nozzle 2 *
0=Not used
11=Enable to reset complete output
13=Enable to call output
0
.15 Call Signal, Side B Logical Nozzle 2 *
0=Not used
11=Enable to reset complete output
13=Enable to call output
0
