Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.04 Vapor Recovery subsystem test, Side B
(Wayne Vac)
F35 Side A Wayne VAC A/L
Calibration Data
.00-.01 Wayne Vac calibration .00=100
.01=100
F36 Side B Wayne VAC A/L
Calibration Data
00-.01 Wayne Vac calibration .00=100
.01=100
F37 Satellite Configuration
Side A
.0N Satellite Delivery type (Can Master & Sat
hoses run at same time), 1=Simultaneous,
0=Non-Simultaneous
.01-1
.1N Physical nozzle number assignment, 0-8, 0 =
None assigned
see model chart at
end
.2N Product type assignment
1=Non-blend
2=Blend
.21=1
.3N Primary meter number assignment, 0-8, 0 =
None assigned
see model chart at
end
.4N Secondary meter number assignment, 0-8, 0
= None assigned
see model chart at
end
.5N Primary valve number assignment 0-8, 0 =
None assigned
see model chart at
end
.6N Primary valve type
1=On/off
2=Proportional
3=Two stage ASCO
4=Two stage Parker
.61=2 (3 or 4 for
UHC models)
.7N Secondary valve number assignment, 0-8, 0
= None assigned
see model chart at
end
.8N Secondary valve type
1=On/off
2=Proportional
3=Two stage ASCO
4=Two stage Parker
.81=2
.9N Satellite Indicator (unit price display) .91=0
F38 Satellite Configuration
Side B
.0N Satellite Delivery type (Can Master & Sat
hoses run at same time), 1=Simultaneous,
0=Non-Simultaneous
.01-1
.1N Physical nozzle number assignment, 0-8, 0 =
None assigned
see model chart at
end
.2N Product type assignment, 1 = Non-blend, 2 =
blend
.21=1
.3N Primary meter number assignment, 0-8, 0 =
None assigned
see model chart at
end
.4N Secondary meter number assignment, 0-8, 0
= None assigned
see model chart at
end
.5N Primary valve number assignment 0-8, 0 =
None assigned
see model chart at
end
.6N Primary valve type
1=On/off
2=Proportional
3=Two stage ASCO
4=Two stage Parker
.61=2 (3 or 4 for
UHC models)
.7N Secondary valve number assignment, 0-8, 0
= None assigned
see model chart at
end
