Dover Wayne Select S1 User Manual

90 Dover Fueling Solutions W2940305 Rev 07 8/2019
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
F28 Side B Dispenser
Configuration
.00 Button input for local authorize function
0=Disabled (set for MPI Auth)
8=Standalone (Requires jumper on display)
8 0
.01 MPI Authorization, Side B, logical nozzle 1
0=Disabled
6=Switch 6 (normal when enabled)
7=Switch 7
0 6
.02 MPI Authorization, Side B, logical nozzle 2
0=Disabled
6=Switch 6 (normal when enabled)
7=Switch 7
0
.03 Attendant arming switch
0=Disabled
6=Switch 6 (normal when enabled)
7=Switch 7
0
F29 Side A Liter Flow Rate
Configuration
.0N Max. slow flow rate, 3-50 (units of .1
liters/min.) For SHC units, see note in
F31.01.
.01=20
.1N Min. slow flow rate, 0-50 (units of .1
liters/min.), 0 = no minimum
.2N Max. fast flow rate, 10-180 (units of
liters/min.) For SHC units, see note in
F31.01.
.21=100
.3N Min. fast flow rate, 0-180 (units of liters/min),
0 = no minimum
F30 Side B Liter Flow Rate
Configuration
.0N Max. slow flow rate, 3-50 (units of .1
liters/min.) For SHC units, see note in
F31.01.
.01=20
.1N Min. slow flow rate, 0-50 (units of .1
liters/min.), 0 = no minimum
.2N Max. fast flow rate, 10-180 (units of
liters/min.) For SHC units, see note in
F31.01.
.21=100
.3N Min. fast flow rate, 0-180 (units of liters/min),
0 = no minimum
F31 Side A Gallon Flow Rate
Configuration
.0N Max. slow flow rate, 1-10 (units of .1
gallons/min.) Note: For SHC units w/ two
meters, enter half of the desired total
amount.
5
.2N Max. fast flow rate, 3-48 (units of
gallons/min.) For SHC units, see note in
F31.01.
26
F32 Side B Gallon Flow Rate
Configuration
.0N Max. slow flow rate, 1-10 (units of .1
gallons/min.) For SHC units, see note in
F31.01.
5
.2N Max. fast flow rate, 3-48 (units of
gallons/min.) For SHC units, see note in
F31.0N.
26
F33 Password Change .00 Service Engineer password, maximum of 6
characters (numeric only)
.01 Station Manager password, maximum of 6
characters (numeric only)
.02 Station Operator password, maximum of 6
characters (numeric only)
.03 Weights & Measures password, maximum of
6 characters (numeric only)
F34 Diagnostics .01 Switch test N = nozzle, S = Stop Switch, B =
bitbus, P = Preset
.02 Display Test
.03 Vapor Recovery subsystem test, Side A
(Wayne Vac)
