Dräger Infinity Series User Manual

Technical Data
VF4 Infinity Gamma Series Page D-7
Infinity Docking Station (IDS) Power Supply
59 55 393 E530U
CAUTION: This Power Supply has a switch used to select
nominal line operating voltage. Make sure that the switch is in
the correct position for your nominal voltage as indicated on the
power supply itself. Incorrect position of the switch could result
in damage to the supply and injury to personnel. For further
details, refer to the installation instructions.
Connections AC Power Connector, DC Power Cable/Connector,
Potential Equalization Conductor
Cooling Convection
Dimensions 135 mm (w) x 111 mm (d) x 270 mm (h)
(5.3” x 4.4” x 10.6”)
Without mounting bracket the depth is 71 mm (2.8”).
Weight 1.85 kg (4.1 lbs)
Power Requirements 100-120VAC, 3.4 A or 200-240VAC, 1.7 A (switch
selectable)
Mains Frequency 50/60 Hz
Power Output +13 VDC, 10.8 Amps
Protection Class Class I
Chassis leakage current <300
µ
A @120VAC, <500
µ
A @220VAC
Mode of Operation Continuous
Ingress Protection Ordinary
Environmental
Requirements
Temperature:
(operating:) 10 to 40 °C (50 to 104 °F)
(storage:) -40 to 70 °C (-40 to 158 °F)
Relative Humidity:
(operating:) 20 to 95%, non-condensing
(storage:) 10 to 95%, with packaging
Atmospheric Pressure:
(operating:) 525 to 795 mmHg (70 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
