Dräger Infinity Series User Manual

Page D-8 Infinity Gamma Series VF4
Infinity Docking Station (IDS) Power Supply
(55 84 912 E530U and 59 49 271 E530U)
Connections AC Power Connector, DC Power Cable/Connector,
Potential Equalization Conductor
Cooling Convection
Dimensions 135 mm (w) x 111 mm (d) x 270 mm (h)
(5.3” x 4.4” x 10.6”)
Without mounting bracket the depth is 71 mm (2.8”).
Weight 1.85 kg (4.1 lbs)
Input Voltage Range 55 84 912 E530U: 100-120 VRMS, 200 - 240 VRMS
59 49 271 E530U: 200-240 VRMS
Mains Frequency 50/60 Hz
Power Consumption 55 84 912 E530U: 3.4 A
59 49 271 E530U: 1.6 A
Power Output +13 VDC, 10.8 Amps
Protection Class Class I
Chassis leakage current <300
µ
A @120VAC, <500
µ
A @220VAC
Mode of Operation Continuous
Ingress Protection Ordinary
Environmental Require-
ments
Temperature:
(operating:) 10 to 40 °C (50 to 104 °F)
(storage:) -40 to 70 °C (-40 to 158 °F)
Relative Humidity:
(operating:) 20 to 95%, non-condensing
(storage:) 10 to 95%, with packaging
Atmospheric Pressure:
(operating:) 525 to 795 mmHg (70 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)
Note that 55 84 912 E530U is for use with input voltage range of 100-120 VRMS,
and 59 49 271 E530U is for use with input voltage range of 200-240 VRMS.

Dräger Infinity Series Specifications

General

Manufacturer	Dräger
Device Type	Patient Monitor
Weight	5 kg to 10 kg (depending on the model and configuration)
Connectivity	Ethernet, USB, WLAN (optional)
Parameters Monitored	ECG, SpO2, NIBP, Temperature, Respiration
Alarm System	Visual and audible alarms, customizable alarm limits
Device Category	Medical Device
Series	Infinity
Display	Color TFT
Display Size	12.1 inches
Power Supply	AC Power, Internal Battery
Battery Life	Up to 4 hours (depending on configuration)
