Vigor2120 Series User’s Guide
183
4
4
.
.
5
5
.
.
3
3
F
F
i
i
l
l
t
t
e
e
r
r
S
S
e
e
t
t
u
u
p
p
Click Firewall and click Filter Setup to open the setup page.
To edit or add a filter, click on the set number to edit the individual set. The following page
will be shown. Each filter set contains up to 7 rules. Click on the rule number button to edit
each rule. Check Active to enable the rule.
Available settings are explained as follows:
Item Description
Filter Rule
Click a button numbered (1 ~ 7) to edit the filter rule. Click
the button will open Edit Filter Rule web page. For the
detailed information, refer to the following page.
Active
Enable or disable the filter rule.
Comment
Enter filter set comments/description. Maximum length is
23–character long.
Direction
Display the direction of packet.
Src IP / Dst IP
Display the IP address of source /destination.
Service Type
Display the type and port number of the packet.
To Next Page
