Vigor2120 Series User’s Guide
488
del [idx]
It means to remove the selected port redirection setting.
disable [idx]
It means to inactivate the selected port redirection setting.
enable [idx]
It means to activate the selected port redirection setting.
flush
It means to clear all the port mapping settings.
table
It means to display Port Redirection Configuration Table.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> srv nat portmap add 1 game tcp 80 192.168.1.11 100 wan1
> srv nat portmap table
NAT Port Redirection Configuration Table:
Index Service Name Protocol Public Port Private IP Private
Port ifno
1 game 6 80 192.168.1.11 100 -1
2 0 0 0 -2
3 0 0 0 -2
4 0 0 0 -2
5 0 0 0 -2
6 0 0 0 -2
7 0 0 0 -2
8 0 0 0 -2
9 0 0 0 -2
10 0 0 0 -2
11 0 0 0 -2
12 0 0 0 -2
13 0 0 0 -2
14 0 0 0 -2
15 0 0 0 -2
16 0 0 0 -2
17 0 0 0 -2
18 0 0 0 -2
19 0 0 0 -2
20 0 0 0 -2
Protocol: 0 = Disable, 6 = TCP, 17 = UDP
Telnet Command: srv nat trigger
This command allows users to set port redirection table for NAT server.
srv nat trigger n [-<command> <parameter> | ... ]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
n
It means the index number for the profiles.
The range is from 1 to 20.
[-<command>
<parameter> | ... ]
The available commands with parameters are listed below.
[…] means that you can type in several commands in one
