Vigor2120 Series User’s Guide
517
e.g.,,
vpn setup 1 name1 l2tp_out 1.2.3.4 vigor 1234 192.168.1.0
255.255.255.0
For Dial-In
<index>
It means the index number of the profile.
<name>
It means the name of the profile.
<ip>
It means the IP address allowed to dial in.
<usr> <pwd>
It means the user and the password required for the
PPTP/L2TP connection.
<key>
It means the value of IPsec Pre-Shared Key.
<nip> <nmask>
It means the remote network IP and the mask.
e.g.,
vpn setup 1 name1 dialin 1.2.3.4 vigor 1234 abc 192.168.1.0
255.255.255.0
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> vpn setup 1 name1 dialin 1.2.3.4 vigor 1234 abc 192.168.1.0
255.255.255.0
% Profile Change Log ...
% Profile Index : 1
% Profile Name : name1
% Username : vigor
% Password : 1234
% Pre-share Key : abc
% Call Direction : Dial-In
% Type of Server : ISDN PPTP IPSec L2TP
% Dial from : 1.2.3.4
% Remote NEtwork IP : 192.168.1.0
% Remote NEtwork Mask : 255.255.255.0
>
