Vigor2120 Series User’s Guide
519
“ctype=t” means PPTP.
“ctype=s” means IPSec.
“ctype= l” means L2TP(IPSec Policy None).
“ctype= l1” means L2TP(IPSec Policy Nice to Have).
“ctype= l2” means L2TP(IPSec Policy Must).
dialto
It means Server IP/Host Name for VPN. (such
as draytek.com or 123.45.67.89).
ltype
It means Link Type.
“ltype=0” means “Disable”.
“ltype=1” means “64kbps”.
“ltype=2” means “128kbps”.
“ltype=3” means “BOD”.
oname
It means Dial-Out Username.
“oname=admin” means to set Username = admin.
opwd
It means Dial-Out Password
“opwd=1234” means to set Password = 1234.
pauth
It means PPP Authentication.
“pauth=pc” means to set PPP Authentication = PAP&CHAP.
“pauth=p” means to set PPP Authentication = PAP Only
ovj
It means VJ Compression.
“ovj=on/off” means to enable/disable VJ Compression.
okey
It means IKE Pre-Shared Key.
“okey=abcd” means to set IKE Pre-Shared Key = abcd.
ometh
It means IPSec Security Method.
“ometh=ah/” means AH.
“ometh=espd/espda/” means ESP DES without/with
Authentication.
“ometh=esp3/esp3a/” means ESP 3DES without/with
Authentication.
“ometh=espa/espaa” means ESP AES without/with
Authentication.
sch
It means Index(1-15) in Schedule Setup.
sch=1,3,5,7 Set schedule 1->3->5->7
rcallb
It means Require Remote to Callback.
“rcallb=on/off” means to enable/disable Set Require Remote
to Callback.
ikeid
It means IKE Local ID.
“ikeid=vigor” means Set Local ID = vigor.
For Dial-In Settings
itype
It means Allowed Dial-In Type. Available settings include:
“itype=t” means PPTP.
“itype=s” means IPSec.
