SECTION 5 MAINTENANCE
Page 52
OM560C99/1E DRESSTA
LOADER EQUIPMENT
To replace the bucket carry out as follows:
1. Park the machine on level ground or in the workshop.
2. Place the bucket in position as shown in Fig. 5.59.
3. Remove bolts 1 and tap pins 2 out.
4. Move away with the machine or lift the boom.
5. Protect disassembled O-rings 3 and 1.5 mm shims 4.
6. Reinstall the bucket in the reverse order.
IMPORTANT: Allowable gap between bucket supports and boom arms is 1.5 mm. If gaps are
bigger, fill symmetrically with shims.
WARNING! When replacing the bucket take care. Disassembled heavy compo-
nents of loader linkage system (boom arms, connector) must be securely
protected against sudden movement.
