DRESSTA 560C - Loader Equipment

SPECIFICATIONS SECTION 6
Page 19
DRESSTA OM560C99/1E
6.9. 560C LOADER EQUIPMENT
A- bucket w/teeth B- bucket w/o teeth
Fig. 6.9. Spade Nose Buckets
Bucket capacity 5.35 cu. m., 5.73 cu. m and 5.73 cu. m.
Applications – quarry
A- bucket w/teeth B- bucket w/o teeth
Fig. 6.10. Straight Edge Buckets
Bucket capacity 5.35 cu.m.,6.5 cu. m., 11.5 cu. m.
Applications – reloading operations 6.5 cu. m., light materials (coal, coke) 11.5 cu. m.
