SPECIFICATIONS SECTION 6
Page 21
DRESSTA OM560C99/1E
STANDARD METRIC FASTENERS
Chart 1
Nominal Thread Diameter
[mm]
Standard Torque ±±10%
[Nm]
6 10
7 16
8 23
10 46
12 80
14 125
16 200
18 275
20 385
22 530
24 670
27 980
30 1330
33 1790
36 2325
6.11. TORQUE VALUES FOR STANDARD ENGLISH FASTENERS
Chart 2 provides tightening torque for general purpose applications using original equipment
standard hardware as listed in the Parts Catalog for the machine involved. DO NOT SUBSTITUTE.
Original equipment standard hardware is defined as Type 8, coarse thread bolts and nuts and thru
hardened flat washers (Rockwell "C" 38-45), all phosphate coated and assembled without
supplemental lubrication (as received) condition. Phosphate coated bolts used in tapped holes in
steel or gray iron, phosphate coated bolts used with phosphate coated prevailing torque nuts (nuts
with distorted threads or plastic inserts), phosphate coated bolts used with copper plated weld nuts.
Markings on bolt heads or nuts indicate material grade ONLY and are NOT to be used to determine
required torque.
