SECTION 3 MACHINE TRANSPORT AND STORAGE
Page 4
OM560C99/1E DRESSTA
MACHINE TRANSPORT
REAR LIGHTS
Fig. 3.3. Rear Lights
Rear lights are mounted on pivotable brackets 1, Fig. 3.3. Lights positioned as shown in the drawing
above, conform to traffic regulations. To change rear lights position:
1. Undo and remove bolt 2.
2. Turn bracket 1 in required position.
3. Reinstall the bolt in hole 3 and tighten.
ATTENTION: It is recommended to change position of lights (brackets) before machine transport
to prevent damage.
3.1. 2. TRANSPORTATION ON TRAILER, RAILWAY CAR OR BY SEA
1. When using automotive trailer or railway car for transportation of the machine, you should take
into account state, local and railway regulations obligatory in particular country or region. If
necessary, co-ordinate the details of transportation and safety measures with competent
authorities.
2. During transportation by the sea, when it is necessary to carry the loader by means of a crane,
use the method of fastening the loader that will ensure maximum safety of persons loading the
machine and will not result in damage of the machine. The lifting slings used for fastening the
loader should be attached only to special lifting lugs marked with special plates on the machine,
refer to Fig. 3.4.
3.1. 3. TRANSPORTATION BY MACHINE OWN DRIVE
ATTENTION ! Long distance driving is forbidden. Short distance driving is permitted under special
circumstances, i.e. from unloading place to workplace.
1. The passage conditions must be coordinated with local road traffic administration.
2. Observe traffic regulations ensuring safe travel.
3. Place boom and bucket in carry position.
4. Interlock the working system control lever and unlock the articulated frame by setting the
connector in the neutral position as shown in Fig. 3.1.
5. Detailed information on safety precautions when operating – see Section 2 SAFETY
PRECAUTIONS.
