SECTION 4 OPERATING
Page 22
OM560C99/1E DRESSTA
SEAT BELT
Fig. 4.11. Adjusting the Belt Length
4.6. CAB HEATING AND VENTILATION
4.6.1. DEFROSTER FAN
Fig. 4.12. Defroster Fan
The fan is designed for cab ventilation (air circulation) and defrosting or defogging the windshield.
The switch has two positions and is located on the side control panel. (Fig. 4.6. item 35). Move the
switch up to operate the fan.
WARNING! Turn off the engine before adjusting defroster fan to avoid hand
injury.
4.6.2. HEATER
For cab heating, ventilation and air conditioning integrated heater and air conditioner installed in right
hand side of the cab wall is used. The heater and air conditioner controls are situated in side control
panel.
