SECTION 4 OPERATING
Page 8
OM560C99/1E DRESSTA
UNIVERSAL SYMBOLS FOR INSTRUMENTS AND CONTROLS
59. Contour Light
60. Work Light
61. Search Light
62. Flash Light
63. Turning Signal Light
64. Front Floodlights
65. Rear Floodlights
66. Dome Light
67. Instrument Panel Illumination Light
68. Backup Light
69. Emergency Light
70. Windshield Wiper
71. Rear Window Wipers
72. Window Washer
73. Mirror Heating
74. Fan
75. A/C
76. Receptacle 24 V
77. Electric Lighter
78. Neutral Position
79. Slow
80. Outside Air for Heating (Blue)
81. Recirculation Air for Heating (Red)
82. Roll Back of Multi-Purpose Bucket
83. Hold of Multi-Purpose Bucket
84. Dump of Multi-Purpose Bucket
85. Closing of Grapple
86. Hold of Grapple
87. Opening of Grapple
88. Boom With Bucket Raise
89. Boom With Bucket Hold
90. Boom With Bucket Lower
91. Boom With Bucket Float
92. Bucket Roll Back
93. Bucket Dump
94. Ground Driven System
95. Change of Direction: Forward- Reverse
96. RSM- Ride Control
97. Quick Coupler Connected
98. Quick Coupler Disconnected
4.3. INSTRUMENTS AND CONTROLS
GENERAL
Before operating the machine you must be thoroughly familiar with the location and use of all
instruments and controls.
WARNING: Understand all control functions before starting the engine.
Each reference number in the illustrations of this section has a corresponding reference number
and explanation in the text.
