MANUAL PC-200
Ver. 2.12.xx/10/22/2010-UK
Page 15 (61)
DI 4. P2 Motor protector
Signal indicates activated motor protection for the pump. This signal does not block the pump as the motor
protector has to be reset manually externally.
.
DI 5. Not used / P3 Not in Auto
If only two pumps are set in the application setting this input will not be used and you will see “Not in
use” text in the digital input 5 menu.
A contact from the manual-0-auto switches used to register when a pump is not in the auto position. When all
pumps are in the auto position the AUTO diode will show a fixed yellow light. If a pump is not in auto position
the Auto diode will show a flashing yellow light and the actual pump will show with | 1 | in the information
window.
DI 6. Overflow / P3 Motor protector
Depending on if the application is for two pumps, the function for this input is
Overflow input
▼▲
▼▲
- Here you set if the input is used or not.
- Here you set the signal type NO or NC
- Here you set the alarm function : Yes or No
- Here you set the alarm delay.
▼▲
6 . O v e r f l o w ►
◄◄
▼▲
▼▲
- Here you set if the input is used or not.
- Here you set the signal type NO or NC
- Here you set the alarm function Yes or No
- Here you set the alarm delay.
-.
▼▲
▼▲
▼▲
-- Here you set if the input is used or not.
- Here you set the signal type NO or NC
- Here you set the alarm function : Yes or No
- Here you set the alarm delay.
▼▲
F u n c t i o n
◄ n o t i n u s e
S i g n a l t y p e
◄◄ N C
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 1 . 0
4 . P 2 M o t o r p r o t . ►
◄◄
F u n c t i o n
◄ n o t i n u s e
S i g n a l t y p
◄◄ N C
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 1 . 0
F u n c t i o n
◄ i n u s e
S i g n a l t y p e
◄◄ N C
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 1 . 0
5 . P 3 N o t i n A u t o ►
◄◄
